Fender Equipment Trailers
Trailer Sales of Indiana is proud to offer Quality, Lamar, and Sure Trac brand fender equipment trailers. Featuring heavy-duty frames and swing up loading ramps these trailers get the job done at a great price. Switch between the tabs to compare values or give us a call today at (317) 743-0020 to purchase one of our fender equipment trailers.
Quality Brand Fender Equipment Trailers
GENERAL DUTY Quality Brand Fender Equipment Trailer
Heavy duty frame with 24″ cross member spacing, radial tires, 2 ft. dove tail, rubber mounted sealed beam lighting in enclosed light boxes, conventional wiring with gel filled connectors.
GVWR 10000 lb.:
16ft. – $4,790
18ft. – $4,990
- Capacity 8500 lb. with 1500 lb. Hitchload
GVWR 12000 lb.:
18 ft. – $5,190
- Capacity 10200 lb. with 1800 lb. Hitchload
GVWR 14000 lb.:
18 ft. – $5,690
20 ft. – $5,890
- Capacity 12000 lb. with 2000 lb. Hitchload
*Standard pricing listed. Additional options extra.
Specifications:
- Treated wood deck
- 82” between fenders
- Braking axles with 4 wheel brakes
- GVWR 10000 lb: 5200 lb. braking axles with 4 wheel brakes
- GVWR 12000 lb: 6000 lb. braking axles with 4 wheel brakes
- GVWR 14000 lb: 7000 lb. braking axles with 4 wheel brakes
- Suspension
- GVWR 10000 lb: Double eye spring suspension
- GVWR 12000 lb: Double eye spring suspension
- GVWR 14000 lb: Slipper spring suspension
- 235/80 R16 load range E 10 ply rating Castle Rock Radial tires
- 6″ channel frame
- 3″ channel cross members – 24” spacing
- 6″ channel wrap around tongue
- 5 ft. swing up ramps with support foot
- 2 5/16″ adjustable coupler
- 7000 lb. drop-foot jack
- Heavy duty diamond plate fenders with backs
- Steps in front and behind fenders
- Stake pockets
- Self charging break away kit, safety chains, skip DOT reflective tape and all rubber mounted lighting with conventional wiring with gel filled connectors
- Primed, 2 coats of acrylic enamel, pin striped
[ back to top ]
PROFESSIONAL DUTY Quality Brand Fender Equipment Trailer
Heavy Duty frame with 16″ cross member spacing, 2 ft. dove tail, premium radial tires, toolbox with lockable lid, LED rubber mounted sealed beam lighting in enclosed boxes with sealed modular wiring harness.
GVWR 15000 lb.:
18ft. – $5,990
20 ft. – $6,190
- Capacity 13000 lb. with 2000 lb. Hitch load
*Standard pricing listed. Additional options extra.
Specifications:
-
- Treated wood deck
- 82” between fenders
- 7000 lb. braking axles with 4 wheel brakes
- Slipper spring suspension
- 235/80 R16 load range E 10 ply rating West Lake Radial tires
- 6″ channel frame
- 3″ channel cross members – 16” spacing
- 6″ channel wrap around tongue with toolbox and lockable lid
- 5 ft. swing up ramps with support foot. These are extra heavy duty ramps made of 4″ channel with spring assist.
- 2 5/16″ HD adjustable cast iron coupler
- 12000 lb. drop-foot jack
- Heavy duty diamond plate fenders with backs
- Steps in front and behind fenders
- Self charging break away kit, safety chains, full DOT reflective tape and all rubber mounted LED sealed beam lighting with U.S. made sealed modular harness with 2 year warranty
- Primed, 2 coats of acrylic enamel, pin striped
To view more details on Quality Trailers website click here.
Decided you don’t want to hassle with ramps? Check out our Tilt Trailers.
[ back to top ]
Lamar Brand Fender Equipment Trailers
Lamar Brand Fender Equipment Trailers
H627831814K – 14,000 GVWR 83” x 18’ w/ 2ft. Dovetail & Standup Ramps: Weight – 2,800 lbs; Payload – 11,200 lbs – $5,990
H627832014K – 14,000 GVWR 83” x 20’ w/ 4ft. Dovetail & Rhino Ramps: Weight – 2,910 lbs; Payload – 11,090 lbs – $6,690
H6271022214K – 14,000 GVWR 102” x 20’ (Driveover Fenders) w/ 4ft. Dovetail & Standup Ramps: Weight – 3,420 lbs; Payload – 10,580 lbs – $6,890
14,000 GVWR 102” x 22’ (Driveover Fenders) w/ 4ft. Dovetail & Rhino Ramps: Weight – 3,725 lbs; Payload – 10,275 lbs – $7,390
*Standard pricing listed. Additional options extra.
Specifications:
Brakes & Suspension:
- Varies by GVWR
- 7K Easy Lube Electric Brake Spring Axles
- Tandem Axle Configuration (14k-16k GVWR)
Tires:
- Varies by GVWR
- 235/80 R16 (E)10Ply Tire With Black Wheel – 14,000 GVWR Model
Frame:
- 16″ Spaced Crossmembers
- Straight Deck
- Removable Diamond Plate Fenders (Standard on 83″ Wide)
- Drive Over Fenders (Standard on 102″ Wide)
- Treated Yellow Pine Floor
- 6″ Channel Frame
- Wrap Tongue
Hitch:
- 2-5/16″ 21K Demco Adjustable Cast Iron Coupler
Jack:
- Single 10K Drop-Leg Jack
Cargo Loading:
- Pair Of Slide-In Ramps – Standard
- Rhino Ramps – Optional add on
- Rub Rail
- Standard Stake Pockets
Electrical:
- Led Lights
- Weather Resistant Harness (-65°F)
Color:
- Lamar Charcoal Gray Powder Coat
Loading Angles:
- 2′ Dove with 57″ Slide In Ramps – 18°
- 2′ Dove with 24″ Stand Up Ramps – 18°
- 4′ Dove with 57″ Slide In Ramps – 14°
- 4′ Dove with 24″ Stand Up Ramps – 14°
- 4′ Dove with Rhino Ramps – 15°
For more information or to view this trailer on Lamar Trailers website click here.
Decided you don’t want to hassle with ramps? Check out our Tilt Trailers.
Sure Trac Fender Equipment Trailers
The Pro Series® Equipment Trailer is the ultimate partner for the professional contractor who needs a trailer as tough and reliable as the equipment it hauls. Imagine heading to the job site, knowing your trailer is built to handle whatever you throw at it—day after day. This is a trailer designed not just to transport your tools and machines, but to support your demanding workload with strength, durability, and thoughtful features that make a real difference.
22′ (19’+3′) Long x 83″ Wide Pro Series Fender Equipment Trailer – $8,290
Additional Options Cost:
Upgrade to 235/85 R16 14 Ply Tires – $500 (4 Tires)/$600 (4 Tires + Spare)
Flip-Up Winch Box w/ 12K Winch w/ Wireless Remote – $2,500
2 5/16 Adj Ball Hitch 25K Upgrade – $100
Click here for to view the specs sheet of this trailer.
Decided you don’t want to hassle with ramps? Check out our Tilt Trailers.
[ back to top ]
Contact Us Today For Fender Equipment Trailers in Indiana
Call us at (317) 743-0020 or fill out the form below and one of our friendly sales associates will be in touch. Thank you.
