Hillcrest 14,000 GVWR Dump Trailers
Hillcrest 83"x14' Telescopic Dump Trailers are built tough with premium 7K or 8K axles, forward self-adjusting brakes, and a heavy-duty slipper spring suspension. Equipped with a 12-ton telescopic cylinder, 8" I-beam tongue, and 12,000 lb jack, they’re ready for serious work. Available in 14K with 14' or 16' lengths, and finished in Sherwin Williams Super Durable Powder Paint, these trailers deliver strength, function, and lasting style. Call us at (317) 743-0020 to get yours today!
Available 14,000 GVWR Dump Trailer Sizes
- 83″x14′ w/ 24″ Sides. Weight 4,405 lbs. Capacity 9,595 lbs
- 83″x14′ w/ 40″ Sides. Weight 5,132 lbs. Capacity 8,868 lbs
- 83″x16′ w/ 24″ Sides. Weight 4,680 lbs. Capacity 9,320 lbs
- 83″x16′ w/ 40″ Sides. Weight 5,530 lbs. Capacity 8,470 lbs
Standard Specifications
Frame & Structure
- 8″ I-Beam Tongue, 13LB
- 8″ I-Beam Frame, 13LB
- 3″ Channel Cross-Members on 12″ Centers
- 7 Gauge Floor
- 24″ or 40″ Sides
- Formed Strong Top Rail
- Stake Pockets Along Both Sides
- Double Broke Fenders
Axles, Suspension & Brakes
- 2 – 7000# Premium, Cambered Axles with Quick-Lubricating Hubs
- Multi-Leaf Slipper Spring w/ Equalizer
- Forward Self-Adjusting Electric Brakes on Both Axles
Coupler, Jack & Safety
- 2-5/16″ Adjustable Coupler
- 12,000# Top Wind, Drop Leg, Set-Back Jack
- 3/8″ Grade 70 Safety Chains with Latch Hooks (2 ea)
- Rear Stabilizer Stands
Electrical & Lighting
- 7-Way RV Trailer Plug
- Sealed Modular Wiring Harness
Tires & Running Gear
- ST235/80 R-16 Load Range E Radial Tires – 8 Lug
- (6) 5/8″ D-Rings Inside Bed for Cargo Control
Hydraulics
- Power Up / Gravity Down Hydraulic System
- 12-Ton 3-Stage Telescopic Cylinder
Gates & Loading
- Rear Combo Gate (Barn Doors & Spreader Gate)
- 6.5′ Standard or Heavy Duty Ramps
- Rear Stabilizer Stands
Convenience Features
- Convenient Side-Step for Easy Access
- Along-Side J-Hooks for Cargo Control
- Lockable Pump and Battery Box Mounted in Front of Bed
Tarp & Protection
- Fully-Formed Tarp Shroud with Tarp & Rear Tarp Rod Holders
Options
- Hydraulic Jack/s
