Car Tilt Trailers

Standard Power Car Tilt Trailer – 10,000 GVWR

10,000 GVWR 20ft. with Winch Plate

GVWR: 10,000 lb.
Capacity: 7,000 lb.

Standard Specifications:

• Diamond Plate Deck – power up and power down tilt
• 80” Between Fenders
• Two 5,200 lb. Dexter Brand Braking Drop Axles
• Double Eye Spring Suspension
• 225/75 R15 Load Range E10 Ply Rating Westlake Radial Tires
• 6″ Channel Frame
• 3″ Channel Crossmembers – 16” Spacing
• 6” Channel Tongue
• 2 5/16″ Adjustable Coupler
• 7000 lb. Drop Foot Jack
• Heavy Duty Removable Diamond Plate Fenders
• D-Ring Tie Downs
• Safety Chains And Break-a-Way Switch
• LED Rubber Mounted Sealed Beam Lighting With Reflective Tape
• Spare Tire Mount
• Primed with epoxy primer and two coats of polyurethane paint

[ back to top ]

Hawke Brand HD Car Tilt Trailers – 15,000 GVWR

Standard Specifications:

• Diamond Plate Deck – power up and power down tilt
• 80” Between Fenders
• Two 7,000 lb. Dexter Brand Braking Drop Axles
• Slipper Spring Suspension
• 235/85 R16 Load Range G14 Ply Range Westlake Radial Tires
• 8″ Channel Frame
• 3″ Channel Crossmembers – 12” Spacing
• 6” Channel Tongue
• 2 5/16″ Cast Iron Adjustable Coupler
• 12000 lb. Drop Foot Jack
• Heavy Duty Removable Diamond Plate Fenders
• D-Ring Tie Downs
• Safety Chains And Break-a-Way Switch
• LED Lighting With Reflective Tape
• Primed with epoxy primer and two coats of polyurethane paint

To view more information on these trailers on Hawke Trailers website click here.

Decided you want a Split Tilt Equipment Trailer with a part tilting, part fixed bed, click here.

[ back to top ]

Standard Specifications (7,000 GVWR – 9,990 GVWR)

Dimensions

• Length: 18′-22′
• Width: 83″
• Deck Height: 22″
• Tilt Angle: 13 Degrees

Construction

• Tongue: 5” Channel

• Frame: 5” Channel

• Crossmembers: 3” Channel, 24” on-center

Axles & Suspension

• Axles: 3,500 lb Dexter Grease Electric Brake (7,000 GVWR Model), 5,200 lb Dexter Grease Electric Brake (9,990 GVWR)

• Suspension: Multi-Leaf Spring

Coupler & Jack

• Coupler: 2-5/16” Adjustable

• Jack: (1) 7,000 lb Drop-Leg

Wheels & Tires

• Wheels: 15” 5-Hole

• Tires: ST205/75 R15 LRC (7,000 GVWR Model), ST225/75 R15 LRD (9,990 GVWR Model)

Hydraulics

• Cylinder: 3” x 10” x 1.25” Cylinder. Power Up/Power Down.

Deck & Tail

• Deck: Full Tilt Deck

• Tail: 1/8″ Steel Diamond Plate Knife Edge

• Floor: Treated Wood Flooring

Fenders & Tie-Downs

• Fenders: Removable Smooth Plate Tear Drop

• D-Rings: (4) 3″ Weld-on D-rings

Lighting & Wiring

• Lights: LED Stop, Tail, & Clearance Lights

• Wiring: 16 Ga. 5-Way Double-Insulated Wire Harness

• Plug: 7-way Cold Weather Cord

Finish

• Pretreatment: Mechanical and/or Chemical Pretreatment for Maximum Paint Adhesion

• Finish: Black Sherwin-Williams Powdura OneCure (Primer w/Polyester TGIC Gloss Powder Topcoat)

Options

• Winch Plate
• Oak Floor Upgrade
• Front Tool Box
• 12″ or 16″ OC Cross-Members

Decided you want a Split Tilt Equipment Trailer with a part tilting, part fixed bed, click here.
